iLivTouch®Non-invasive Liver Disease Management System

The iLivTouch® series is Hisky Medical’s non-invasive liver disease management solution, integrating advanced Vibration-Controlled Transient Elastography (VCTE/TE) and ultrasound imaging technologies. By providing quantitative liver stiffness measurement (LSM) and ultrasound attenuation assessment（UAP）, iLivTouch® systems support liver fibrosis staging, steatosis evaluation, and treatment monitoring across multiple clinical settings.

Non-invasive

Quantitative

Rapid

Accurate

UAP

Ultrasound Attenuation Parameter, dB/m

Assessment of Liver Steatosis

LSM

Liver Stiffness Measurement, kPa

Assessment of liver Fibrosis

LivQ-box LIID*

Liver disease Quantitative-box Liver Inflammatory InDex

Assessment of MASH

SSM*

Spleen Stiffness Measurement

Assists in portal hypertension evaluation, significantly improves the endoscopy exemption rate

SUP*

Splenic Ultrasound Parameters

Assists in portal hypertension evaluation, significantly improves the endoscopy exemption rate

Parameters marked with an asterisk are for research use only.

Department of Liver Diseases and Infections

Department of Endocrinology

Department of Gastroenterology

Physical Examination Center

Department of Ultrasonography

Department of Hepatobiliary Surgery

Clinical Applications

The iLivTouch^® system supports a wide range of clinical applications, including:

- Chronic hepatitis B and C management

- Metabolic dysfunction-associated steatotic liver disease (MASLD)/MAFLD assessment

- Liver steatosis monitoring

- Liver fibrosis and cirrhosis evaluation

- Treatment response assessment and follow-up

The Technical Advantages of iLivTouch®

Ultrasound guidance

Scientific and intuitive locating method

Wideband frequency probe

Applicable to patients of different body sizes

TE + Ultrasound Diagnosis

Multi-functional device

Multi-mode fusion probe

Integrating ultrasound imaging and elasticity measurement

Multichannel tissue information scanning

The detection sample volume is 30cm³, which is 1000 times larger than liver biopsy sample volume

This technology is available in some models. For details, please refer to the specific product models.

Voice of Authority

iLivTouch® Series

Mini Series

FT Series

Pro Series

Plus Series

Max Series





Mini Series

Applied Technology

Vibration-Controlled Transient Elastography (TE)

Examination Method

Probe touch detection

Data Processing

Optimized scientific algorithms

Convex Probe

Fibrosis Scanning Probe

Dynamic wideband frequency, real-time transmitting and receiving ultrasonic waves,controlled low-frequency shear wave

Function

• Liver Stiffness Measurement (LSM)
• Ultrasound Attenuation Parameter (UAP)

Other Product Information

• 7kg of weight. easy to carry around
• 3 hours of battery life for remote use
• Fully featured with the ability to test LSM and UAP
• Compatible with add-on ultrasound probe*
• CE & US FDA: FT100, Mini800

FT Series

Applied Technology

Vibration-Controlled Transient Elastography (TE), 2D imaging technology

Examination Method

Probe touch detection

Data Processing

Optimized scientific algorithms

Convex Probe

Scanning depth >200mm, real-time transmitting and receivingultrasonic wave

Fibrosis Scanning Probe

Dynamic wideband frequency, real-time transmitting and receiving ultrasonic waves,controlled low-frequency shear wave

Function

• Liver Stiffness Measurement (LSM)
• Ultrasound Attenuation Parameter (UAP)
• Assessment of liver tissue morphology by 2D ultrasound

Other Product Information

• Image-guided Ultrasound for accurate positioning
• 19”high-resolution LCD to better visualize the testing process
• Integrated design brings stable performance
• FT1000: CE
• FT9000: CE, US FDA

Pro Series

Applied Technology

Vibration-Controlled Transient Elastography (TE), 2D imaging technology

Examination Method

Probe touch detection

Data Processing

Optimized scientific algorithms

Convex Probe

Scanning depth >200mm, real-time transmitting and receivingultrasonic wave

Fibrosis Scanning Probe

Dynamic wideband frequency, real-time transmitting and receiving ultrasonic waves,controlled low-frequency shear wave

Function

• Liver Stiffness Measurement (LSM)
• Ultrasound Attenuation Parameter (UAP)
• Assessment of liver tissue morphology by 2D ultrasound

Other Product Information

• Image-guided Ultrasound for accurate positioning
• 21.5”high-resolution LCD to better visualize the testing process
• Integrated design brings stable performance
• Pro9000: CE

Plus Series

Applied Technology

Vibration-Controlled Transient Elastography (TE), 2D imaging technology

Examination Method

Probe touch detection

Data Processing

Optimized scientific algorithms

Convex Probe

Scanning depth >190mm, real-time transmitting and receiving ultrasonic wave

Fibrosis Scanning Probe

Dynamic wideband frequency, real-time transmitting and receiving ultrasonic waves,controlled low-frequency shear wave

Function

• Liver Stiffness Measurement(LSM)
• Ultrasound Attenuation Parameter (UAP)
• Assessment of liver tissue morphology by 2D ultrasound

Other Product Information

• Color Doppler system available for color ultrasound application in abdomen
• Simultaneous determination of LSM and UAP
• Build-in touchscreen for easy operation
• Plus9000: CE

Max Series

Applied Technology

MigTE(Multichannel image guided Transient Elastography), Color DopplerUltrasound Guidance

Examination Method

Probe touch detection

Data Processing

Optimized scientific algorithms

Convex Probe

Multi-mode Fusion Probe, wideband frequency

Fibrosis Scanning Probe

Support ultrasound examination of abdomen, e.g. liver, pancreas, spleen,kidney, etc.

Function

• Liver Stiffness Measurement(LSM)
• Ultrasound Attenuation Parameter (UAP)
• Color Doppler Ultrasound Guidance

Other Product Information

• One Multi-Mode Fusion Probe does ultrasound imaging and measurement of liver stiffness and UAP
• Multichannel and large-scale tissue information reconstruction,detection sample volume is 30cm3
• Dual display of multiple results on one screen
• High-end color doppler ultrasound assists in diagnosis
• FH9000: CE

Learn more about product tech  Learn about related clinical research 

If you need more product information, please contact us.
